廚房內送、排風口的布置應按灶具的具體位置加以考慮，不要讓送風射流擾亂灶具的排風性通。確定送風出口的入口風速時，送風口應沿排風罩方向布置，而排風口距排風罩越遠越好。

　　The arrangement of the air supply and exhaust outlets in the kitchen should be considered according to the specific location of the cooker, so that the ventilation of the cooker can not be disturbed by the air jet. When the inlet wind speed of the air supply outlet is determined, the air outlet shall be arranged along the direction of the exhaust hood, and the distance from the exhaust hood to the exhaust hood is better.

　　山東通風管道加工安裝油煙凈化裝置之前，要對排煙系統(tǒng)中各部分的實際運行參數，包括運行阻力和排風量進行核算。

　　Before the installation of lampblack purification equipment for ventilation pipes in Shandong, it is necessary to calculate the actual operating parameters of the exhaust system, including the operation resistance and exhaust air volume.

　　如果是新建項目，設計時要充分考慮裝置了油煙凈化器后對排風系統(tǒng)的影響;如果是改造項目，加裝油煙凈化器時需要對排風系統(tǒng)重新進行核算，必要時要對集煙罩、排煙管道和廚房整體補風裝置進行改造并更換排煙風機。

　　If the new project design to fully consider the impact on the exhaust system for fume purifier; if installed fume purifier renovation project, need to re check the exhaust system, when necessary for collecting hood, exhaust pipe and air supply device of kitchen renovation and replacement of the exhaust fan.

　　廚房排煙管道的水平段不宜太長，水平末端設活接頭，以方便清理油垢。以防風速過低使油附著于煙道上， 如果在裝油煙凈化器之前，引風機已經裝好無法挪動的情況下，建議選擇將油煙凈化器裝在引風機的末端，但是前提：油煙凈化器的末端必需加裝向下的90°彎頭，或者向上90°彎頭加防雨帽，因為油煙凈化器里面不能進水，里面的高壓電場怕聯電引起不必要的麻煩。

　　The exhaust pipe of the horizontal section of the kitchen should not be too long, the level set the end of union, to facilitate the removal of grease. The wind speed is too low to make the oil attached to the flue, if installed before the fume purifier has been installed to move under the condition of fan, recommended to choose the end, lampblack purifier installed in the fan but the premise: the end of oil smoke purifier must be installed 90 degrees bend downward or upward, 90 degrees bend with the rain hat, because the oil fume purifier which can not be afraid of water, the high voltage electric field inside the UMC cause unnecessary trouble.

　　以上便是山東通風管道加工今天的分享，您還滿意嗎，歡迎關注我們的網站:http://www.cdxysh.cn/并且關注我們的產品，我們將為您提供的產品，衷心的愿與您建立合作關系。

　　The above is Shandong ventilation pipe processing today's share, you are satisfied, welcome to pay attention to our website: http://www.cdxysh.cn/ and pay attention to our products, we will provide you with good products, sincerely willing to establish a cooperative relationship with you.
